The HP Integrity SuperDome.

Machine type	RISC-based ccNUMA system.
Models	HP 9000 SuperDome.
Operating system	HP-UX (HP's usual Unix flavour)
Connection structure	Crossbar
Compilers	Fortran 77, Fortran 90, Parallel Fortran, HPF, C, C++
Vendors information Web page	http://www.hp.com/products1/servers/integrity/superdome_high_end/
Year of introduction	2000.

System parameters:

Model	Integrity SuperDome
Clock cycle	1.5 GHz
Theor. peak performance
Per proc. (64-bits)	6 Gflop/s
Maximal (64-bits)	768 Gflop/s
Main memory
Memory/node	≤ 128 GB
Memory/maximal	1 TB
No. of processors	≤ 128
Communication bandwidth
aggregate (global)	64 GB/s
(cell—backplane)	8 GB/s
(within cell, see below)	16 GB/s

Remarks:

The Integrity Superdome is HP's investment in the future for high-end servers. Within a timespan of a few years it should replace the PA-RISC-based HP 9000 Superdome. HP has anticipated on this by giving it exactly the same macro structure: cells are connected to a backplane crossbar that enables the communication between cells. For the backplane it is immaterial whether a cell contains PA-RISC or Itanium processors. For a discussion of the macro architecture see the Remarks part of the HP 9000 Superdome. Also within a cell the structure of the system is very similar: an identical Cell Controller ASIC as in the HP 9000 Superdome is the central hub that controls local memory access, I/O requests, and communication to the other cells via the backplane.
The difference lies in the processor, the 1.5 GHz Itanium 2. HP managed to make a special processor socket that allows 2 Itaniums to be placed in one socket. Therefore 8 Itaniums in total can be housed in the four sockets on the cell board. As each Itanium contains 2 floating-point units that are able to execute a combined floating multiply-add instruction, in favourable circumstances 4 flops/cycle can be achieved and a Theoretical Peak Performance of 6 Gflop/s per processor can be attained. This amounts to a peak speed of 768 Gflop/s for a full configuration.
Because the similarity between the both Superdome systems is so large, the Integrity Superdome has the same ccNUMA characteristics as its relative. It therefore supports OpenMP over its maximum of 128 processors. As the Integrity Superdome is based on the Itanium 2 for which much Linux development is done in the past few years, the system can also be run with the Linux OS. In fact, because the machine can be partitioned, it is possible to run both Linux and HP-UX in the different complexes of the same machine. The remark as for the HP 9000 Superdome applies: in different complexes one can employ cells with different types of processors, making the system a hybrid Integrity and HP 9000 Superdome.

Measured Performances:
In [42] a speed of 1049 Gflop/s is reported for solving a full linear system of unspecified size. This result is achieved on a complex of systems with a total of 220 processors. As the Theoretical Peak Performance of such a cluster is 1320 Gflop/s the efficiency is 79%.
